AOM-S3108M-H8L
RAID/HBA Card Supermicro AOM-S3108M-H8L 240xHDD LSI SAS 3108
You can check our refurbished list on our blog https://www.serverparts.cz/en/blog?q=refurbished
Net: $ 631.94
Gross: $ 777.29
Availability: EOL
Manufacturer: Supermicro
Part number: AOM-S3108M-H8L
Warehouse product ID: 58197
Availability*: PL: NoneNL: 1 pcs. (estimated delivery time from 4 to 10 business days)
* Please remember that delivery times are also influenced by events beyond our and the manufacturer's control, such as random events, armed conflicts or natural disasters.
Delivery cost: $ 7.24 net ($ 8.90 gross)
(the indicative cost of delivery on Poland's territory)
The indicative delivery cost in EU - 20€ DHL/30€ UPS
Kluczowe cechy / Key features :
1. Broadcom 3108 8-port PCI-E SAS-3 controller
2. 8-port (8 internal) 12Gb/s per port
3. Supports RAID 0, 1, 5, 6, 10, 50, 60
4. On board hardware IO Processor
5. 2GB 1866MHz DDR3 on-card cache
6. MegaRAID configuration and management utilities
7. Power management support
8. SAS transfer rates up to 12Gb/s and SATA rates up to 6Gp/s
9. Optional Cachecade feature for higher performance
10. Supports SSP, SMP, STP and SATA protocols
11. Optional Supercap/TFM Unit for cached data protection, (BTR-CV3108-U1) - operating temperature (Ambient)
from 10°C - 55°C
12. OS Support : Windows 2012, 2k8 64/32 bit, Red Hat, Enterprise and SUSE Linux
13. Power Usage 16W
Product description
We try to be as accurate as possible, however we do not guarantee that the product descriptions on our site are current or error free.
Please verify them on the manufacturer's website by clicking this link.
| Manufacturer | Supermicro |
|---|---|
| SKU | AOM-S3108M-H8L |
| Basic informations | |
| Chipset | LSI SAS 3108 |
| Type | HW |
| RAID type | 0,1,5,6,10,50,60 |
| Max. HDD # | 240 |
| NVMe support | No |
| Ports external # | 0 |
| Ports internal # | 8 |
| Interface | SAS2, SATA3 |
| Cache | 0MB |
| BBU | N/DMB |
Product description errors? Please let us know.
